E&B Lab by IMS Superfine Filter Basket

RM139.00 MYR
Choose size
Rendering loop-subscriptions

From the expertise and the knowhow of IMS, E&B Lab developed a wide range of innovative filters.

Each filter is electro-polished with a cylindrical shape, and it is available in five heights.

The innovation is the Nanoquartz technology on all the surface of the filters.

Moreover, E&B Lab presents a new filter, the Superfine, for an higher filtration.

In this way, E&B Lab gives the baristas the opportunity to exalt all the hints of its coffee.

---------------------------------------------------------------------------------------

The Super-Fine filter comes from the idea of creating a filter with a higher filtration power than standards.

Usually the filtration is between 250 and 350-μm.
The super-fine filter has a filtration capacity of 170-μm. To achieve this performance, we combined a 170-μm membrane to IMS holing technology.



PRODUCT CODE              HEIGHT              CAPACITY

B702TH24SF                    h.24 mm              14/16 gr
B702TH26SF                    h.26 mm              16/18 gr
B702TH28SF                    h.28 mm              18/20 gr


SHAPE
BORDER: Ø 70 mm (B70)
BODY: Ø 60 mm for Ø 58 mm tamper
RIDGELESS

FILTRATION
SuperFine filtering membrane 170 µm
PERFORATION
PERFORATED AREA: Ø 40 mm
NUMBER OF HOLES: 565
The number and distribution of the holes are designed to support the filtering membrane and to balance the flow.

FINISHING
TUMBLING: Wet vibrofinishing with ceramic inserts and drying with corncob
PICKLING: Passivation and preparing of the material
ELECTROPOLISHING: smooth surface with unmatched sanitary and non-contaminating qualities is obtained.
