Pinecone Swiss Foxtail
Commercial Shop Grinder
Foxtail
The Foxtail is for roasters, wholesalers, retailers and everyone else in need of a commercial shop grinder that is capable of grinding over 2.5 kg /
5 lbs of coffee per minute. Three-phase power,
120 mm flat discs with a range from Turkish fine to cold brew and a high-capacity hopper ensure even the highest volume demands can be met day in day out.
Equipment uptime is maximized by Foxtail's new and innovative service concept of easily replaceable pre-assembled modules for the grinding and electrical components. Contact your service partner to send in your module and receive a new or refurbished replacement module the next day rather than spending your precious time with repairs.
technical details
Motor configurations: 208V, 60 Hz, 3Ph, 1.500 W
380-415V, 50 Hz, 3Ph, 1.800 W
Disc diameter: 120 mm
Disc material: steel
Disc lifetime: 15-20 tons
Grinding output: 2.5 kg per minute
Hopper capacity: 2.5 kg
Weight: 49 kg (gross, packaged)
37 kg with hopper installed (net)
Dimensions (W x H x D): 250 x 810 × 320 mm (with hopper installed)
Packaging (W x H x D): 275 x 690 × 505 mm (grinder)
400 × 320 × 315 mm (hopper)
